Midea 3 Ton Cassette Type Non-Inverter Air Conditioner (MCA36CR

Description

Midea 3 Ton Cassette Type Non-Inverter Air Conditioner (MCA36CR)
General
SKU MMCA36CREHT
Brand Midea
Warranty Information 5 Years Official Warranty
Cooling Specifications
Cooling Capacity 36000 BTU
Airflow Volume Indoor: 1600/1500/1400
Temperature Range 16°C-31°C
Energy Efficiency
Energy Star Rating 3
Power Consumption Up to 5350W (Rated Input)
Voltage/Frequency 380-410V, 3Ph, 50Hz
Current (Amps) Rated Current: 11.7A
Power Input Up to 5350W (Rated Input)
Compressor and Refrigerant
Refrigerant Charge 2.4kg
Compressor Type Rotary
Refrigerant Type R410
Build and Design
Remote Control Yes
Indoor Unit Dimensions Front Panel Body (W x D x H): 950 x 45 x 950 mm
Outdoor Unit Weight 71.2Kg
Indoor Unit Weight 25Kg
Outdoor Unit Dimensions 980 x 410 x 1210 mm (W x D x H)
Smart and Convenience Features
Noise Levels (Outdoor) Hi: 59.5 dB
Noise Levels (Indoor) (Hi/Mi/Lo): 50/48/46 dB
Description
Specifications of Midea 3 Ton Cassette Type Non-Inverter Air Conditioner (MCA36CR)
Specifications:
Type: Cassette Type
Energy Saving: Non-Inverter
Function: Cooling Only
Cooling Capacity (Btu/H): 36000 BTU/hr
Cooling Standard Current (A): Up to 8.2A
Cooling Standard Input (W): Up to 4000W
Cooling Rated Current (Max Current): Up to 11.7A
Cooling Rated Input (Max Input): Up to 5350W
Cooling EER (W/W): 3.1
Cooling EER (BTU/Hr)/W: 9
Cooling Star Rating: Star 3
Power Supply (V-Ph-Hz): 380-410V, 3Ph, 50Hz
Gas Type: R410
Gas Amount: 2.4Kg
Controller Type: Remote
Compressor Type: Rotary
Compressor Brand: LAMDA
Suction Pressure (MPA): 4.2
Discharge Pressure (MPA): 1.5
Operation Temperature: 16°C – 31°C
Pipe Size (Liquie side, Gas side) (Inch): 3/8, 5/8
Drain Pipe Size (mm): OD32
Indoor Air flow: 1600/1500/1400 (m3/h)
Indoor Noise Level (Hi/Mi/Lo) (dB): 50/48/46
Outdoor Noise Level (Hi/Mi/Lo) (dB): 59.5
